    3S-3.8S Telescopic Bollards Retractable Bollards For Driveway


    The Retractable Bollard System is designed for high-security applications, featuring a rapid rising mechanism that allows bollards to deploy in just 3 to 3.8 seconds. This efficient system effectively controls vehicle access while ensuring pedestrian safety in various environments.


    Product Parameter
    Part NumberRPL-LB01
    Rise Time3.8S
    Fall Time3S
    Equipment Sizeφ400*1105mm
    Interception Height600mm
    Cylinder Diameter219,273,324mm
    Column Thickness6,8,10mm
    Embedded Depth1105mm
    Cylinder304 stainless steel
    Column ThicknessThickness 6mm
    Flange304 stainless steel
    Flange Thickness10mm
    Embedded bucketA3 steel powder spraying
    Piston Rod45 gauge steel chrome plated
    Cylinder Head45 gauge steel chrome plated
    Piston Rod Diameter16mm
    Hydraulic Cylinder HousingNo. 45 steel spraying
    Guide RailAnti-rust hardening treatment
    Rail Diameter16mm
    Reflective FilmHigh brightness diamond grade reflective film
    LED Warning LightsHighlight, Colorful, Gradient
    Power UnitElectro-hydraulic integrated actuator
    Lifting Force130kg
    Protection ClassIP67
    Power Supply220VAC(Control Voltage 24VDC)
    System Power350W
    Usage Frequency1.5 Times/Minute
    Movement overheating protection130°C
    Heating EquipmentNone
    Fuel Tank Capacity4L
    Operating Temperature-20~55

    3S-3.8S Telescopic Bollards Retractable Bollards For Driveway

    Key Features:

    1. Fast Deployment: The quick rising time of 3 to 3.8 seconds ensures minimal delay in vehicle management, enhancing operational efficiency during busy periods.

    2. Durable Construction: Made from robust materials, these bollards are built to withstand harsh weather conditions and resist impacts, ensuring longevity and reliability.

    3. Advanced Control Mechanism: The system can be integrated with access control technologies, including RFID readers, remote controls, and traffic management systems.

    4. Safety Features: Equipped with sensors to detect obstacles, the bollards automatically stop or retract if a vehicle or pedestrian is in the way, ensuring safety during operation.

    5. Aesthetic Variety: Available in multiple designs and finishes, the bollards can be customized to match the aesthetic of the surrounding environment while providing effective security.

    3S-3.8S Telescopic Bollards Retractable Bollards For Driveway


    Benefits:

    • Enhanced Security: Provides a robust barrier against unauthorized vehicle entry, making it ideal for secure facilities, government buildings, and event venues.

    • Efficient Traffic Management: The quick response time allows for smooth control of vehicle flow, reducing congestion and improving access management.

    • User-Friendly Operation: Simple control options enable quick activation and deactivation, allowing security personnel to manage access effortlessly.

    • Versatile Applications: Suitable for various settings, including shopping centers, airports, public spaces, and any location requiring controlled vehicle access.


    3S-3.8S Telescopic Bollards Retractable Bollards For Driveway
    ● Before leaving the factory, all products are subjected to strict aging tests according to the "Realpark Smart Product Testing Process" before they can be delivered. The factory products are not damaged by human beings, and all of them provide 1-year warranty service and life-long maintenance.


    3S-3.8S Telescopic Bollards Retractable Bollards For Driveway


    The software team has introduced numerous advancements in the control system, enhancing product applications and significantly extending product lifespan. Additionally, the integration with ground sensors, infrared systems, barrier gates, access gates, and license plate recognition has become more efficient and logical. Currently, Realpark products support platform-based control, and capabilities for data collection and platform integration have been successfully implemented.


    3S-3.8S Telescopic Bollards Retractable Bollards For Driveway

    Applications of Retractable Bollard System

    The Retractable Bollard System is a flexible and effective security solution that can be deployed in various settings. Here are some key applications:

    1. Government Facilities: Used to secure access points to sensitive buildings, controlling vehicle entry while allowing authorized personnel to pass easily.

    2. Event Venues: Ideal for managing vehicle access during events, ensuring the safety of pedestrians and controlling traffic flow in crowded areas.

    3. Shopping Malls: Helps regulate vehicle access to parking areas and pedestrian zones, enhancing safety and improving the shopping experience.

    4. Airports: Provides security at terminal entrances and restricted areas, allowing quick access for authorized vehicles while preventing unauthorized entry.

    5. Public Transportation Stations: Effective for controlling vehicle access to bus and train stations, ensuring passenger safety and reducing congestion.

    6. Corporate Campuses: Secures company premises by restricting vehicle access to authorized personnel, enhancing security in corporate environments.

    7. Residential Communities: Improves safety in gated neighborhoods by controlling vehicle entry and ensuring only residents and authorized guests can access the area.

    8. Military Bases: Acts as a strong barrier against unauthorized vehicles, enhancing security at military installations.

    9. Critical Infrastructure Sites: Protects sensitive facilities such as power plants and water treatment facilities by controlling vehicle access.

    10. Urban Centers: Used in city streets to manage vehicle flow and enhance pedestrian safety, allowing for flexible access control during peak traffic times.

    The Retractable Bollard System is a versatile solution that enhances security and traffic management across a wide range of applications.


    3S-3.8S Telescopic Bollards Retractable Bollards For Driveway


    Rising Bollard System FAQs:

    • What is a Retractable Bollard System?

      • A retractable bollard system is a security installation that allows bollards to rise and lower to control vehicle access while ensuring pedestrian safety.
    • How long does it take for the bollards to rise?

      • The bollards can be deployed within 3 to 3.8 seconds, allowing for quick access management.
    • What materials are the bollards made from?

      • The bollards are typically constructed from durable materials like stainless steel or reinforced aluminum to withstand harsh conditions.
    • Can the system be integrated with other security technologies?

      • Yes, the system can be integrated with access control systems, including RFID readers, remote controls, and surveillance cameras.
    • Are the bollards suitable for outdoor use?

      • Absolutely, the bollards are designed to be weather-resistant and can be effectively used in outdoor environments.
    • How do the bollards ensure safety during operation?

      • The system is equipped with sensors that detect obstacles, preventing the bollards from rising or lowering if a vehicle or person is in the way.
    • What are the power requirements for the system?

      • The bollards typically operate using standard electrical power, with options for battery backup in case of outages.
    • Can the bollards be customized in terms of design?

      • Yes, the bollards can be customized in various designs, colors, and finishes to match the aesthetics of the installation site.
    • Is training required to operate the system?

      • While the system is user-friendly, basic training is recommended for effective operation and maintenance.
    • What types of locations benefit from using retractable bollards?

      • They are ideal for high-security areas, government buildings, shopping centers, airports, and public spaces requiring controlled vehicle access.
